Microcomputer High-Frequency Inverter Spot Welding Machine 2000W Fiber Laser for Aluminum and Copper Welding

Product Name: Microcomputer High-Frequency Inverter Spot Welding Machine 2000W Fiber Laser for Aluminum and Copper Welding.

Brand Name:AS-XD –LM2000W

Product Origin:China

Product description: This 2000W continuous fiber laser welding machine combines a 1070nm wavelength laser with precision galvanometer technology, achieving ±0.03mm positioning accuracy. Designed for 1.0-1.8mm aluminum/copper sheets, it delivers 35% photoelectric efficiency and IP54 protection for 24/7 industrial operations.

This 2000W continuous fiber laser welding machine combines a 1070nm wavelength laser with precision galvanometer technology, achieving ±0.03mm positioning accuracy. Designed for 1.0-1.8mm aluminum/copper sheets, it delivers 35% photoelectric efficiency and IP54 protection for 24/7 industrial operations.

Configuration Name	Model	Specification
Laser Galvanometer Welding Head	Main Body Structure	Standard
	Self - made Air Knife Blowing Device	Standard
	Preview	Red Light Alignment
	Field Lens	F100
Chiller	Chiller Tank Main Body	Constant - temperature Water Tank
Chiller	Filter Element	Standard 3P Filter Element
Machine Tool Main Body	Structural Working Range	Length 800×Width 580×Height 400MM
Machine Tool Main Body	Machine Tool Exterior Cover	Precision Sheet Metal
Laser	2000W	Wavelength 1070NM
	Serial Connection Cable	RS232 Interface
	15 - meter Fiber Cable	Imported 50UM Core Fiber Cable
Drive Motor	Servo Motor	Standard
Drive Motor	Photoelectric Limit	Standard
Welding Software	Control System	DA Multi - function Welding Control Software
Industrial Computer	Industrial - grade Computer	4G Memory, Intel Core CPU 3.2G, 120G Solid - state Drive
Industrial Computer	Monitor	DELL 19 - inch Industrial Monitor
CCD Camera Vision System	CCD	Automatic Vision Positioning
Auto - focus System	XD - DJ	Automatic Focus Ranging

Technical Specifications

1.Machine Tool Technical Parameters

Item		Technical Parameter
Overall Machine Dimensions		1560mm1360mm2100mm
Chiller Dimensions		1455mm885mm645mm
Maximum Processing Size (mm)		800*580mm
Maximum Workpiece Height (mm)		400mm
Effective Travel	X - axis (mm)	800mm
	Y - axis (mm)	580mm
	Z - axis (mm)	400mm
Positioning Accuracy	X - axis (mm)	±0.03mm
	Y - axis (mm)	±0.03mm
	Z - axis (mm)	±0.02mm
Repeatability	X - axis (mm)	±0.05mm
	Y - axis (mm)	±0.05mm
	Z - axis (mm)	±0.02mm
Rapid Positioning Speed	X - axis (m/min)	60m/min
	Y - axis (m/min)	60m/min
	Z - axis (m/min)	15m/min
Protection Rating		IP54

2.Laser Parameters

Item	Technical Parameter
Working Mode	Continuous/Modulated
Laser Power (W)	2000W
Laser Wavelength (nm)	1070
Fiber Core Diameter	50UM
Maximum Modulation Frequency (KHz)	Continuous
Laser Mode	Yv04
Beam Quality (M2)	＜0.373
Power Adjustment Range (%)	0 - 100
Fiber Length (m)	15 meters
Cooling Method	Water - cooled
Working Temperature (℃)	25
Long - term Working Stability (24h)	Good
Focal Length F (mm)	200
Focus Adjustment Range (mm)	-5—+5
Rated Power (Kwh)	≦16KW

3.Working Environment Requirements

1	Working Environment Temperature	10℃-35℃
2	Relative Humidity	30%-80%
3	Surrounding Environment	Well - ventilated, no impact within 5 meters
4	Power Voltage	220v
5	Power Frequency:	50Hz
6	Grounding Type	Direct Grounding Type
