Model: AS-BD-50ML
Product Name: Battery Electrolyte Filling Machine
Automatic Digital Battery Electrolyte Filling Machine Injector For Lab Research.
Description:
The AS-BD-50ML is a new generation bottle top burette and dispenser. More accurate and convenient titration. It is an excellent tool as an electrolyte dispenser; dispensing up to 50mL per batch for Lithium-Ion Battery research.
Parameters:
|
Product Name
|
Battery Electrolyte Filling Machine
|
|
Model
|
AS-BD-50ML
|
|
Precision
|
The Titrette® bottle-top burette has an innovative new measuring system that matches the Class A accuracy of glass burettes and,if needed, can offer the precision of 3 decimal places below 20mL. This is an important feature for users who need to work within the Class A error limits of glass burettes according to DIN EN ISO 385 or within volumetric tolerance per ASTM E287.
|
|
User Serviceable
|
It can be quickly and easily disassembled in a matter of minutes – for cleaning, to replace the piston/cylinder, or to replace the batteries. Maintenance is easy and convenient, without the need to send it out for repair.
|
|
Protection
|
To protect light-sensitive media, the installed clear cylinder inspection windows can be easily replaced with the supplied clip-on amber-colored windows.
|
|
Profile
|
All components move within the housing, reducing headroom requirements. The compact design and lightweight ensure good stability.
The titrating tube can be adjusted horizontally and vertically.
|
|
Operation
|
The large handwheels provide smooth, precise control from rapid to dropwise titration.
|
|
Operating limits and exclusions
|
This instrument is designed for titrating liquids with the following limits:
The temperature of instrument and reagents must be between 15º and 40º C (59º and 104ºF);
Vapor pressure up to 500mbar;
Viscosity up to 500 mm^2/s;
Altitude: Maximum 3000m above sea level;
Relative humidity: 20% to 90%.
|
