Features

Smart design with an air-jet vacuum pump, which allows it can be used  either in air or any inert gas.

Simple design with digital temperature  display for quick operation.

The inert gas filling function is built-in before the vacuum.

Compact design for using at inside glovebox or tabletop.

Working Voltage

AC110V  50/60Hz

Power

1000W, 8A max.

Sealing Area

MAX. Battery Placing Area: 18" W（457 mm ) x 0.5” H （12mm）

Sealing Blade

Dual Copper made sealing blade with rubber buffer (soft-sealing)

Blade with: 7 mm

Preset Max. sealing temperature: 180oC without Controller

Vacuum Level

Max. Vacuum:  - 50 kPa  ( 350 torr )

Vacuum Flow Rate:  6 cfm  ( 28 Liter / minute)

Vacuum time  1- 100 seconds adjustable

The mechanical pump is optional for higher vacuum  ( -90Kpa )

Inert Gas Filling

The inert gas filling port is built in the back to pre-filling inert gas before vacuum

The gas filling time is controlled by a timer:  1- 100 seconds

Sealing Blade Dimension

635 mm L  x  6.35  mm W

Heating Timer

0 - 99 seconds Adjustable

Sealing Temperature

Max. 200°C   adjustable by heating time

Digital temperature display installed

Air Pressure Requirement

>100 PSI air or inert gas source required

if using at outside  glovebox, an air compressor is required

if you at inside glovebox, please use inert gas tank either N2 or Ar

Attention: If a gas cylinder is used instead of an air compressor, a two-stage pressure regulator must be installed on the gas cylinder to limit the pressure within the required working range for safe operation.

Weight

40 Lbs

Product Dimensions

33"x 10"x7“ （without support tray）

Origin

China

Warranty

One year limited warranty with lifetime support
