Lab Flexible Hydrophilic Carbon Cloth for Fuel Cell and Supercapacitor

Model: WOS1011 (It is a updated version of WOS1009)

Manufacturer: Ce-Tech

Note: Hydrophobic is optional.

Lab Flexible Hydrophilic Carbon Clothfor Fuel Cell and Supercapacitor

Model: WOS1011 (It is a updated version of WOS1009)

Manufacturer: Ce-Tech

Note: Hydrophobic is optional.

Size: 10cm*40cm, 20cm*20cm, 20cm*30cm, 40cm*50cm, other size can be customized.

Application:

1. hydrogenfuelcell (PEMFC) use

2. Methanol fuel cell (DMFC) use

3. Supercapacitor lab research

4. Microbial fuel cell use

5. Suitable for growing and depositing materials in liquids (main used for lab)

Features:

1. High strength, Not easy to break

2. Although it has burrs, it is not easy to fall apart after cutting

3. Soft, flexible, can be bent 180 degrees

4. Good conductivity, resistance ratio less than 5mΩcm2

Product Property Test:

		Actually measure a value			AVG	Method
Thickness(mm)		0.35	0.36	0.36	0.36	TECLOCK SM-114
Nominal Basis Weight (g/m2)		126	126	125	126	ASTM D-646
Air Permeability(Gurley)		1.33	1.35	1.28	1.32	Gurley
Resistance(mΩcm2) (Through Plate)		1.88	1.96	1.84	1.89	Base on ASTM C-611
Tensile Strength(N/cm)	MD	12.6	9.6	14.9	12.37	ASTM D-828
Tensile Strength(N/cm)	XD	7.8	7.2	10.2	8.40	ASTM D-828

*D.Carbon cloth (Without Micro Porous Layer and PTFE)

*Resistance(mΩcm2)(Through Plate) four point measurement, copper plate cootact under 200pst testing area 12.6cm2.

Hydrophilic Soft Carbon Cloth
