High Porosity Nickel Metal Foam Sheet for Lithium Ion Battery Electrode

High Porosity Nickel Metal Foam Sheet for Lithium Ion Battery Electrode

Item NO.:Pure Nickel Foam

Product Origin:China

Thickness: 0.5mm 1.0mm 1.5mm 2mm 3mm, can be customized

High Porosity Nickel Metal Foam Sheet for Lithium Ion Battery Electrode

Application field:

Exhaust gas purifier carrier materials, battery electrode materials, all kinds of catalyst carrier, especially for high temperature resistance and acid and alkali corrosion filtering material, the surface of the infrared burner materials, all kinds of industrial and civil heating material drying equipment, etc

Specifications:

Name	Pure Nickel Foam for Battery Current Collector
Thickness	0.5mm 1.0mm1.5mm 2mm 3mm, can be customized
Size	200mm*300mm, customized
Porosity	96%-98%
Purity	≥99.8%
Through Hole Rate	≥98%
PPI	110
Areal density	350±20g/m2
Bulk density	0.1-0.8g/cm3
Tensile Strenth (Longitudinal)	35.3/20mm (Test result)
Tensile Strenth (Transverse)	26.8N/20mm (Test result)
Fe	<200ppm
C	<300ppm
S	<80ppm
Si	<50ppm
Cu	<100ppm
Ni+Co	>997000ppm
Used for super capacitor, nickel hydrogen battery, nickel cadmium battery, fuel cell
Origin	China
Warranty	One year limited warranty with lifetime support
