Vacuum Mixer Mixing Machine for Making Battery Electrode Paste

Product Name: Vacuum Mixing Machine

Max Rotational speed: 310 rpm

Mixing Jars: 304 stainless steel 150ml and 500ml

Dimensions: 33cmL*31cmW*56cmH

Weight: About 27kg

EMAIL

Vacuum Mixer Mixing Machine for Making Battery Electrode Paste


Description:

AS-AX-2000 vacuum mixer machine is designed to produce coating slurry by mixing the small batch of chemicals and compound  under vacuum to remove gas bubble and protect the sample from oxidation.


This battery slurry mixer has a built-in pump that can vacuum the mixing container to -0.08Mpa and the step-less mixing speed around 300rpm. The vibration plate is located at the bottom to remove the gas bubble before vacuum mixing and disperse the slurry after mixing. It is excellent for preparing battery electrode paste and various ceramic materials in a material research lab. It is compact so that you can put in a glovebox with N2 gas (No Ar).


Specifications:

Power supply voltage

AC 220V / 110V 50HZ / 60HZ ±10%

Power

150W

MaxRotational speed

310 rpm

Mixing Jars

304 stainless steel 150ml and500ml

Vacuum Level

-0.08~0.09 MPa

Vacuum pump

Built in single stage vacuum pump

Mixing Time

0~99 Minutes Adjustable

Option

30mL SS container is available at extra cost

Dimensions

33cmL*31cmW*56cmH

Weight

About 27kg

Warranty

One year limited with lifetime support

Compliance

CE only


Vacuum Mixing Machine
